Product Information

My-T-Mouse® On-screen Keyboard for Computers...

...Desktop Computers, Tablet PCs, Touch screen Computers, or for us with any other Pointing Device (Mice, Trackballs, GlidePads, Pens, Switches, Digitizers, Tablets, Touchscreens, etc.), to deliver a powerful user interface, and provide reliable, secure user access and control over all computer functions, just like a physical keyboard.

My-T-Mouse includes hundreds of programmable on-screen keyboard layouts, user programmable macro buttons, and many other innovative user interface approaches to enhance operations within the Microsoft Windows Environment.

"My-T-Mouse" is IMG's original On-screen Keyboard for Tablets, Touch screens, Mice, and other pointing devices. Introduced at Fall Comdex in 1993, it has evolved into hundreds of customized versions for specific applications ranging from Assistive Technology to Automation to Field Service to Enterprise Management tools.

My-T-Mouse On-screen Keyboard for Tablets, Touchscreens, and other pointing devices includes over 200 international layouts with 3D Key display and infinite sizing! The Logon option allows the pointing device (Pen, Touchscreen, or other device) to logon to Windows and enables the evolution beyond the physical keyboard once and for all! The feature list includes all of the requested options found in the versions My-T-Touch and My-T-Pen, including the ability to re-map keys, Custom Logos, Supervisor / Operator modes, and hundreds of other options...

By allowing systems to operate without the need for a physical keyboard, external templates, membranes, or buttons, My-T-Mouse can provide the finishing touch on sealed systems that only require a pointing device interface for user input.

"Heads Up Display" - My-T-Mouse uses a concept found in fighter planes, helicopters, tanks, etc., called "Heads Up Display" technology. Its principal objective is to keep the users focus and concentration centered in one place.

My-T-Mouse uses that concept to reduce the visual re-focusing and re-positioning, caused by the heads up and down motion of going from screen to keyboard to screen, and the resulting confusion it causes. Many users find, with our on-screen keyboard, they no longer need a physical keyboard, membrane panel, or other input device beyond the actual interface (Mouse / Tablet / Touchscreen / Pen / etc.)

  • New features in 1.79
    • Support for Windows 7 / Vista
    • (for Windows 8 / 8.1 (32 & 64 bit) see My-T-Soft)
    • Version match to My-T-Soft, My-T-Pen, and My-T-Touch
    • Workstation / Network Logon Options - both Windows 7 / Vista and XP/2000
    • Even more layouts, now over 200 on screen keyboards providing worldwide coverage
    • Integrated support for Build-A-Board keyboard layouts
    • New configurable location options for users - private or shared
    • More Integrator options
    • Developer Kit add-ons - options to integrate DLLs with My-T-Mouse, Logging capabilities
    • Configuration saving options - after move, after change, at close, at end of session
    • Numerous customer requested enhancements & updates

Features

Over 200 "Heads-Up Display" Infinitely Sizeable Keyboards


Russian on screen keyboard Layout in size 8

ABCD Alphabetical, QWERTY, 3 DVORAK's, and over 200 International layouts [Chinese, Japanese, Korean, German, Spanish, French, Hebrew,
Russian (shown right in size 8), Greek, etc.] with Edit and Numeric panels.

Minimize Keystrokes, Mouse Clicks and Menu Selections


Standard 3D Macro Panel in size 9 Macro Panel in size 7 with custom color Windows Panel in size 7 with custom color Standard Windows Panel

Store up to 2000 keystrokes/menu selections (or the applications macro scripts) on each button. Up to 15 buttons can be grouped on individual Panels, which auto-open when their assigned application becomes active.
Shown Left (far): My-T-Mouse with standard Macro panel open in size 9.
Shown Left (near): My-T-Mouse with Macro panel open in size 7 with customized color option.
Shown Right (near): My-T-Mouse with standard Windows panel open in size 9.
Shown Right (far): My-T-Mouse with Windows panel open in size 7 with customized color option


Pop-up Calculator in size 9

Assignable Functions for Pointing Device Buttons


Assign any of 63 different functions to each button. Popular keys such as Shift, Esc, Enter, Ins, Ctrl, etc, can be assigned at anytime

Pop-Up Calculator with pop-up Tape and Send Function


A standard 4 function calculator with memory, that always stays on top, has its own pop-up Tape and Send function that places the display information right into your current document or field (shown in size 9).


My-T-Mouse with Magnifier Open

Built in Magnifier


If necessary, a built-in Magnifier panel can be displayed to show a magnified view of the current area (mouse cursor as center).

Developer friendly


Show & Hide keys, program keys in Key Options, Custom logo display, Operator mode, on-demand functionality. The Developer's Kit comes with all kinds of utilities, source code, sample code, and a wealth of information for integrating My-T-Mouse with your own application.

Feature List

  • Seamless operation from Mouse, Trackball, Touchscreen, Pen, or any other pointing device

  • Microsoft Windows 2000 / XP / Vista / 7 Compatible

  • Workstation / Network Logon Options

  • Developer Tool Kit and Extensions

  • Developer examples of integrating into existing applications

  • Supervisor / Operator Modes

  • Show & Hide Keys

  • Selectable Sizes

  • Realistic 3D graphics

  • Infinite Sizing

  • Support for Build-A-Board layouts - completely customizable user interface

  • 11 panels, individually selectable, or create your own with Build-A-Board

  • Great for editing - Quick & Easy!

  • Special Windows Short-cut Keyboard - Power Users Dream!

  • 101 & 104 key layouts

  • Multiple Keyboard Layouts with ABC Layout for Non-Typists

  • International support - numerous keyboard layouts from around the world

  • Create Macro Keys & Panels

  • Specific Key & Key Combination Enable / Disable

  • Attach Executable programs to Keys & Key Combos or Window Activation

  • Includes the Calculator with Calculator Tape & Send Feature

  • Time & Date Display

  • Memory, Disk Space, Resources status Display

  • Completely Configurable for all of your needs

  • Built-In Magnifier

  • Color-code Panels for easy identification

  • On-line Quick Help for First-Time Users

  • Minimizes to a Button for convenient access

  • Once you use it, you won't want to live without it!

  • Keyboard not required (Just Say No... to your Keyboard.)

  • End-user and Developer Support

Specifications

On-Screen keyboard software written as standard Windows application
  • Compatible with all properly written Windows applications
  • Developed in C/C++ - written at same level as Windows operating system for maximum capabilities
  • Accesses Windows API via standard interfaces/System DLLs - No frameworks or special environment required
  • Support for all Windows variations since Windows 3.0, including Windows CE
  • Field proven technology since 1993
Keyboard designed so pointing device can fully operate Windows
  • Keyboard layouts as binary data files for minimal space requirements
  • Fully emulates 101/104 physical keyboard
  • 11 individually selectable panels, including Alpha keyboard, Edit, and Numeric keypad
  • 12 base sizes, infinite larger sizes
  • Over 200 US, international, and variation layouts
  • Supports IMG's Build-A-Board Layouts
User, developer, and integrator command and control options
  • Provides ability for user to operate without need for physical keyboard
  • Operator mode for secure application integration
  • Developer's Kit (SDK) for controlling and manipulating keyboard
Modular support options/capabilities
  • Sounds
  • Transparency
  • Windows logon options
  • External Support utilities (Developer's Kit)
Operational customization options
  • Show/Hide keys to remove potentially undesirable keys/options (Alt, Control, Function keys, etc.)
  • Key options to remap/modify key actions
  • Macro panels for arbitrary/lengthy keyboard actions
Visual customization options
  • Custom views/colors/key images
  • Supports themes for visual integration
  • Integrates with IMG's Build-A-Board for complete customization capabilities
Extensive feature list
  • Unique and specialized features to address customer needs
  • Detailed help, documented options, on-line knowledgebase
  • Advanced Technical support, programming, and program level integration assistance available

Technical Information

My-T-Mouse is a standard Windows Application and does not require any special drivers, and should work with all pointing device (mouse, touchscreen, pen, HID, etc.) interfaces, along with keyboard and mouse emulation drivers that are compatible with the ones that ship with Microsoft Windows.

There are countless of configuration options, settings, and special features available that have been added by customer requests since the original product release in 1993. Refer to the User's Guide for release specific technical notes, product options, and complete documentation.

Order - My-T-Mouse


My-T-Mouse Suggested Retail Price is US $99.95.


Just want to license electronically?
Download and install the software, then click on "Purchase License Now" from the License Manager!



For OEM, Integrator & Reseller Pricing or EndUser Single, Multi-Site, or Enterprise Licensing
(including Keyless Licensing, Image Ready integration, and Programming Integration Support),

please call 800-889-0987 (+1 818-701-1579) or contact IMG Sales
